The GCW22P-S is a dedicated single-phase canopy model ideal for standby power in off-grid and on-grid purposes.
GCW22P-S
The GCW22P-S is a dedicated single-phase canopy model ideal for standby power in off-grid and on-grid purposes. The high-quality Perkins diesel engine and Italian made alternator are superbly complemented by a robust, weatherproof enclosure and state of the art digital control panel.
The PowerGen team is here to make sure you find the perfect power source for your business needs. With years of experience and expertise, we can provide expert advice about sales, installation and maintenance so that all fields are covered in-depth with ease!
Main features of GCW22P-S
Frequency: 50Hz
Voltage: 230V
Power factor: cos 1
Phase and connection: 1
Standby power LTP: 18.00 kVA
Standby power LTP: 18.00 kW
Prime power PRP: 16kVA
Prime power PRP: 16 kW
Dry weight (kg): 586
Dimensions (L x W x H / mm): 1645 x 870 x 1072
Fuel tank capacity: 51 L
For installation data check out the Pramac specifications manual attached.
*Specifications are taken from the GCW22P-S catalogue (attached).
Engine specifications for GCW22P-S
Type of engine: Perkins / 404D-22G
[50Hz] Exhaust emission level: Stage IIIA
Engine cooling system: Water
No. Cylinders: 4
Displacement: 2216 cm3
Aspiration: Natural
Speed Governor: Mechanical
Prime Gross Power (PRP): 18.7kW
Max gross power (LTP): 20.6kW
Oil capacity: 10.6 L
Coolant capacity: 7 L
Fuel: Diesel
Specific fuel consumption @ 75% PRP: 238 g/kWh
Specific fuel consumption @ PRP: 237 g/kWh
Starting system: Electric
Starting engine capability: 2 kW
Electric circuit: 12 V
*Specifications are taken from the GCW22P-S catalogue (attached).
GCW22P-S includes:
Base frame made of welder steel profile, complete with:
- Anti-vibration mounting properly sized
- Visual fuel level indicator
- Intergrated support legs
Plastic fuel tank complete with:
- Filler neck
- Air breather (vent pipe)
- External refueling ability
- Oil draining facilities
Canopy
- Single piece hinged soundproof canopy equipped with pneumatic arms and handlesto lift up the canopy allowing easy access to the genset for maintenance purposes.
- Simple handling operationswith central lifting eye
- Soundproof! Noise attenuation thanks to soundproofing material (polyurethane foam) and efficientresidential silencer placed inside the canopy.
