The robust mechanical structure of the Pramac GSW410DO model permits easy access to the connections and components during routine maintenance check-ups. The PowerGen team is here to make sure you find the perfect power source for your business needs. With years of experience and expertise, we can provide expert advice about sales, installation and maintenance so that all fields are covered in-depth with ease!
GSW410DO
The robust mechanical structure of the Pramac GSW410DO model permits easy access to the connections and components during routine maintenance check-ups. The Pramac GSW410DO is mounted on a solid welded steel base frame with anti-vibration mountings, the unit can also come in an enclosure suitable for outdoor use. GSW410DO model is a great choice for any business that needs to power its operations.
The PowerGen team is here to make sure you find the perfect power source for your business needs. With years of experience and expertise, we can provide expert advice about sales, installation and maintenance so that all fields are covered in-depth with ease!
Main features of GSW410DO
Frequency: 50Hz
Voltage: 400V
Power factor: cos 0.8
Phase and connection: 3
Standby power LTP: 404.39 kVA
Standby power LTP: 323.51 kW
Prime power PRP: 363.48 kVA
Prime power PRP: 290.78 kW
Dry weight (kg): 4237
Dimensions (L x W x H / mm): 4494 x 1798 x 2468
Fuel tank capacity: 720 L
For installation data check out the Pramac specifications manual attached.
*Specifications are taken from the GSW410DO catalogue (attached).
Alternator specifications for GSW410DO
Type of engine: Mecc Alte / ECO40-1S/4
Poles: 4
Type: brushless
Standard AVR: DER1-A
Voltage tolerance: 1%
Efficiency at @ 75%: 93.8%
Class: H
IP Protection: 21
Engine specifications for GSW410DO
Type of engine: Doosan / P158LE-1
[50Hz] Exhaust emission level: Non emission certified
Engine cooling system: Water
No. Cylinders: 8 V
Displacement: 14618 cm3
Aspiration: Turbocharged intercooled
Speed Governor: Electronic
Prime Gross Power (PRP): 327 kW
Max gross power (LTP): 362 kW
Oil capacity: 28 L
Coolant capacity: 20 L
Fuel: Diesel
Specific fuel consumption @ 75% PRP: 200 g/kWh
Specific fuel consumption @ PRP: 202.2 g/kWh
Starting system: Electric
Starting engine capability: 7 kW
Electric circuit: 24 V
*Specifications are taken from the GSW410DO catalogue (attached).
GSW410DO includes:
Standards
- The engine performance corresponds to ISO 3046. Ratings are based on ISO 8528.
Fuel System
- In-line pump with integrated electromagnetic actuator
- Fuel Filter full flow, cartridge type with water drain valve
Lubrification System
- Fully forced pressure feed type
- Oil pump Gear type driven by crank- shaft gear
- Oil filter Full flow, cartridge type
Cooling System
- Water circulation by centrifugal pump on the engine
- Cooling method Freshwater forced circulation
- Cooling fan Blower type
