Pramac Sydney mobile energy storage delivers great reliable power that helps bring down costs and in an environmentally sensitive way. The gridtogo™ INGENIUM MX16-30 Li is a universal Energy Storage System (ESS) ideally suited to a range of applications.
INGENIUM MX16-30 Li – Pramac Sydney System
We have brands such as Pramac Sydney at PowerGen!
Pramac Sydney mobile energy storage such as the gridtogo™ INGENIUM MX16-30 Li, unit is fitted with an OPzV-S high cyclic capacity, maintenance free lead acid battery. Alternative battery options are available that include Lead Carbon and Li-Ion NMC offering different properties and to suit specific budgets. Please discuss your needs with a technical advisor to establish the most appropriate specification for your requirements.
The PowerGen team have years of experience and excellent knowledge of amazing brands like Pramac Sydney. We can provide expert advice about sales, installation and maintenance to make sure there proper understanding of the product needed.
Main features of gridtogo™ INGENIUM MX16-30 Li
• 230V 50Hz 1Ø output, 10kVA
• GSM Remote monitoring
• Deep cycle maintenance free OPzV-S battery
• 30kWh stored energy
• Full system DC isolator with pre-charge
• 63A pass-through capacity
• 63A Auto full system bypass
• Integrated smart Solar PV storage capability
• Advanced EMS with smart device control
* *Specifications are taken from the INGENIUM MX16-30 Li catalogue (attached).
Specifications for INGENIUM MX16-30 Li
Input (400/230V 50Hz 3Ø):- | |
AC Maximum input 3Ø or 1Ø | 100A |
System bypass capacity | 100A |
Option for second AC input | 100A |
Output (400/230V 50Hz 3Ø):- | |
Continuous ac (Inverter) | 16kVA |
Inverter peak power (5 seconds) | 32kW |
Pass-through capacity | 100A |
DIMENSIONS: | |
Length | 1600mm |
Height | 1550mm |
Width | 1000mm |
Ingress protection rating | IP34 Suitable for outdoor use |
Standard Finish | Epoxy Powder Coat RAL 9016 |
Noise Levels | Inaudible above background |
Maximum heat rejection | 750kW |
INSTRUMENTS, CONTROLS & CONNECTIONS:- | |
Input connection | IEC 60309 or hardwire stud |
Optional AC2 input | IEC 60309 or hardwire stud |
Output Connections AC | 3Ø 400V IEC 60309 or hardwire stud |
Cascade ready | ✓ |
System status control panel | ✓ |
Battery condition | ✓ |
Battery main isolator | ✓ |
Output MCB’s | ✓ |
Programmable gen auto-start signal | ✓ |
OPTIONAL FEATURES:- | |
Integrated MPPT Solar PV charge controller | ● PV |
High capacity system bypass | ● BPS |
Single to three phase conversion | ● PC |
Harsh environment pack | ● HE |
Free air cooling pack | ● FA |
Standard Battery Options
| Battery Tape | Lead Carbon | Li-Ion NMC |
| Battery design life | 2000 cycles to 80% DoD, 3000 cycles to 60% DoD | 2000 to 80% dod, 4000 to 60% dod |
| Nominal Battery Capacity | 500Ahrs @C10 | 600Ahrs |
| Useable stored energy | 25kWhs | 30kWhs |
| Total unit weight | 1550 kg | 1050 kg |
| Operating temperature range | -20℃ +55℃ | -20℃ +55℃ |
For installation data check out the Pramac Sydney Offgrid specifications manual attached.
*Specifications are taken from the INGENIUM MX16-30 Li catalogue (attached).
